0114 Grey Silicone Thermal Conductive Grease 2.6W/M·K For Thermal Conductivity of Electronic Components

Name: 0114 Grey Silicone Thermal Conductive Grease 26WMK For Thermal Conductivity of Electronic Components
Brand: HUITIAN
Price: 1 USD

China 0114 Grey Silicone Thermal Conductive Grease 2.6W/M·K For Thermal Conductivity of Electronic Components wholesale

Brand Name : HUITIAN

Model Number : 0114

Certification : SGS

Place of Origin : CHINA

MOQ : 60kg

Price : Negotiation

Payment Terms : L/C, T/T

Supply Ability : 1000KG MONTH

Packaging Details : 1kg/bucket,12buckets/carton

Delivery Time : 5-8 days

Physical Form : paste

Color : grey

Main Component : polysiloxane

Density : 2.5g/cm³

Volatility(200℃,24h) : 0.2%

Thermal Conductivity : 2.6 W/(m•K)

Working Temperature : -40-150

Contact Now

0114 TDS-EN.pdf

0114 is a one-component Silicone Thermal Conductive Grease suitable for gap filler and reducing the temperature of electronic components.

Product Features:

One-component, grey;

Physical form: paste;

Wide working temperature range;

Nontoxic, non-corrosive to PCB and metal;

Eco-friendly, odourless;

Its stability and thermal conductivity kept even at the temperature of 150°C, also can be manually glued

Maintain dry and flowing at high temperature;

Thermal conductivity: 2.6W/m·K

Main Applications:

Widely used for the thermal conductivity of electronic components including the filling of gaps between CPU, BGA, LED, power source, high-power audion, thyristor, and basic materials such as copper and aluminum to reduce the temperature of electronic components.

Item	Unit	Typical Value
Item No.		0114
Physical Form		paste
Color		grey
Main Component		polysiloxane
Density	g/cm³	2.5
Penetration Degree	1/10cm	290
Volatility(200℃,24h)	%	0.2
Volume Resistivity	Ω*cm	1.0×10¹⁵
Dielectric Strength	KV/mm	22
Breakdown Voltage	KV/mm	18
Surface Resistance	Ω	1.6×10¹²
0.1mm Thermal Resistance	m²K/W	0.00007
Heat Conductivity Coefficient	W/(m·K)	2.6

Packing:

1kg/bucket, 12buckets/carton

Storage:

Store it in dry and cool places at the temperature of 0~35℃

Shelf life is 12 months

0114 Grey Silicone Thermal Conductive Grease 2.6W/M·K For Thermal Conductivity of Electronic Components
